234552-SHACKLE BOW W/SCREW PIN GALV, GREEN PIN G-4161 32MM 12TON
 IMPA: 234552

234552-SHACKLE BOW W/SCREW PIN GALV, GREEN PIN G-4161 32MM 12TON

BOW SHACKLE SCREW PIN__32x35x51mm WLL 12,0 ton

For IMPA code 234552 with official discription 234552-SHACKLE BOW W/SCREW PIN GALV, GREEN PIN G-4161 32MM 12TON we supply code our item description which is sold per PCE and weights 4.51.

IMPA code number 234552 is available from stock and can be shipped out within 24/hrs to any agent or warehouse in the world. We have 15.000 different IMPA articles in out own stock and IMPA 234552-SHACKLE BOW W/SCREW PIN GALV, GREEN PIN G-4161 32MM 12TON is ready for shipping. Just order online, pay by different ways in a secure eviroment and we ship out your IMPA ( 234552 ) the same day!

Product specification

<p>High quality, high tensile ?Green Pin? shackle can be identified by the green coloured pin and the marking on the shackle body and pin. Green pin shackles meet all relevant requirements of the Machinery Directive 2006/42/EC and all latest amendments. Material: Body and pin high tensile steel, Grade 6, quenched and tempered, Safety Factor: MBL equals 6 x WLL (Working Load Limit), Standard: EN 13889 and meets performance requirements of US Fed. Spec. RR-C-271 Type IVA Class 2, Grade A, Finish: Hot dipped galvanized, Temperature Range: -20?C to + 200?C, Certification: At no extra charges this product can be supplied with a works certificate, material certificate, manufacturer test certificate, EC Declaration of Conformity and all shackles starting from 2 t can be supplied with DNV 2.7-1 certificate.</p>
