234548-SHACKLE BOW W/SCREW PIN GALV, GREEN PIN G-4161 19MM 4.75TON
BOW SHACKLE SCREW PIN__19x22x31mm WLL 4,75 ton
For IMPA code 234548 with official discription 234548-SHACKLE BOW W/SCREW PIN GALV, GREEN PIN G-4161 19MM 4.75TON we supply code our item description which is sold per PCE and weights 1.06.
IMPA code number 234548 is available from stock and can be shipped out within 24/hrs to any agent or warehouse in the world. We have 15.000 different IMPA articles in out own stock and IMPA 234548-SHACKLE BOW W/SCREW PIN GALV, GREEN PIN G-4161 19MM 4.75TON is ready for shipping. Just order online, pay by different ways in a secure eviroment and we ship out your IMPA ( 234548 ) the same day!
234548-SHACKLE BOW W/SCREW PIN GALV, GREEN PIN G-4161 19MM 4.75TON
Sale priceDhs. 0.00
Regular price (/)
Product specification
<p>High quality, high tensile ?Green Pin? shackle can be identified by the green coloured pin and the marking on the shackle body and pin. Green pin shackles meet all relevant requirements of the Machinery Directive 2006/42/EC and all latest amendments. Material: Body and pin high tensile steel, Grade 6, quenched and tempered, Safety Factor: MBL equals 6 x WLL (Working Load Limit), Standard: EN 13889 and meets performance requirements of US Fed. Spec. RR-C-271 Type IVA Class 2, Grade A, Finish: Hot dipped galvanized, Temperature Range: -20?C to + 200?C, Certification: At no extra charges this product can be supplied with a works certificate, material certificate, manufacturer test certificate, EC Declaration of Conformity and all shackles starting from 2 t can be supplied with DNV 2.7-1 certificate.</p>Brand
LOCAL (or mentioned in description)
UOM
PCE
HS Code
73269098
Country of Origin
NETHERLANDS
SKU
SKU-14941
